T250 Series DIN-Rail Power Meter | T250-MD01 | RS-485 | 96×96 Panel Mount

Comprehensive Power Monitoring in a Compact Format

The T250 is a versatile, precision-class multifunction power meter built for real-time energy measurement in modern commercial and industrial environments. Designed for switchboards, subpanels, and energy management systems (EMS/BMS), the T250 provides true RMS readings with Class 0.5S accuracy and advanced harmonic analysis up to the 31st order.

Supporting a range of input configurations (1P2W, 3P3W, 3P4W), the T250 offers key insights into power quality, demand patterns, and system efficiency, all from a compact DIN 96 × 96 mm panel-mount housing. The high-visibility backlit LCD display includes bargraph current indicators and intuitive navigation for field teams and facility engineers.

Standard Modbus RTU (RS-485) communication ensures seamless integration with automation, SCADA, and BMS platforms. Optional modules for relay outputs, analog signals, or digital inputs allow flexible system expansion based on project needs.

Ideal for EMS/BMS integration, THD tracking, and energy optimization.

Key Features

• True RMS: Measures voltage, current, power, energy, and frequency
• Harmonic Analysis: Up to 31st harmonic (voltage & current)
• Input Configurations: 1P2W / 1P3W / 3P3W / 3P4W
• Communication: RS-485 Modbus RTU (T250-MD01)
• Display: Backlit LCD with 4×4 digit display + 3 current bargraphs
• Advanced Monitoring: Demand / Max Demand, CT/VT scaling
• Expandable: Supports relay, analog, and digital input modules (via variants)
• Input Voltage: AC 3–500V L-L / 2–288V L-N
• Power Supply: AC/DC 85–265V
• Mounting: DIN 96×96 | Panel Mount
• Protection: IP52 front, IP30 housing
• Certifications: CE compliant, IEC 62053-22 Class 0.5S


Applications

• Energy Management & Power Quality Systems
• Industrial Load Balancing & Monitoring
• HVAC, Pump Stations, and Power Panels
• Solar Inverter Output Measurement
• Server Farms & Data Centers
• BMS/EMS Projects with Harmonic Distortion Insights


Models

Note: This product is customizable and can be built to order. See the full model list datasheet below and click "Enquire Now" for a quote and guidance on the right version for your project.

Downloads:

• Datasheet
